Cables, Wires and Accessories for Robotics

Robots are an integral part of the manufacturing industry worldwide to the extent that they are indispensable. In production, robots and cobots frequently encounter each other, working and interacting side by side with humans, but also performing tasks independently. The latest industrial robots move in a three-dimensional (3D) space and can therefore perform a wide variety of tasks.

Robotic Cable Forces

The forces acting on robotic cables and wires.

The motion sequences of a robot or a robot arm are repeated millions of times and in all directions. They offer continuous precision and consistent quality for repetitive tasks even under extreme conditions. Strict requirements are placed on robot cables due to strong acceleration and deceleration, loads from tension and 3D stress, a combined stress coming from torsion and bending. They should meet these requirements, but depending on their intended use, they must also be guided in or on the robot arm in a tight and space-saving manner in order to achieve the greatest possible freedom of movement.

Our ROBOFLEX® brand cables offer the right solution for the various loads. The cables cover requirements for chemical, thermal and mechanical stresses in torsion, bending, flexibility, abrasion, notch resistance, oil resistance and weld bead resistance.

HELUKABEL offers cables with different cross sections for robotics in the areas of sensor technology and data, network and bus technology as well as control and motor cables. In addition to a large stock availability of robotic cables and assemblies, HELUKABEL also makes customer-specific solutions possible. Depending on the application, we develop the appropriate cable and the corresponding cable protection system for you and take care of the installation and service onsite.

We are happy to help you select the right products for your specific application and are available to answer any questions you may have.

Call us at +1 289-444-5040 or send us an email at: robotics@helukabel.com

Featured Products

HELUDATA® ROBOFLEX®-D PUR UL/CSA

HELUDATA® ROBOFLEX®-D PUR UL/CSA

PUR robot data cable
UL (AWM) 300V
+90°C
D-shield, EMC-preferred type
Torsion load/cycles: 5 Mio. at +/- 180°/m
Bending cycles: 5 Mio.

Variant: HELUDATA® ROBOFLEX® PUR UL/CSA (Non-shielded)

Spec Info
HELUDATA® ROBOFLEX®-PAIR-D PUR UL/CSA

HELUDATA® ROBOFLEX®-PAIR-D PUR UL/CSA

PUR twisted pair robot data cable
UL (AWM) 300V
+90°C
D-shield, EMC-preferred type
Torsion load/cycles: 5 Mio. at +/- 180°/m
Bending cycles: 5 Mio.

Spec Info
HELUCONTROL® ROBOFLEX®-D PUR UL/CSA

HELUCONTROL® ROBOFLEX®-D PUR UL/CSA

PUR robot control cable
UL (AWM) 600V
+90°C
D-shield, EMC-preferred type
Torsion load/cycles: 5 Mio. at +/- 180°/m
Bending cycles: 5 Mio.

Variant: HELUCONTROL® ROBOFLEX® PUR UL/CSA (Non-shielded)

Spec Info
HELUPOWER® ROBOFLEX®-D PUR UL/CSA

HELUPOWER® ROBOFLEX®-D PUR UL/CSA

PUR robot motor cable
UL (AWM) 1000V
+90°C
D-shield, EMC-preferred type
Torsion load/cycles: 5 Mio. at +/- 180°/m
Bending cycles: 5 Mio.

Variant: HELUPOWER® ROBOFLEX® PUR UL/CSA (Non-shielded)

Spec Info
HELUPOWER® ROBOFLEX® HYBRID-D PUR UL/CSA

HELUPOWER® ROBOFLEX® HYBRID-D PUR UL/CSA

PUR robot power & signal hybrid cable
UL (AWM) 1000 V
+90°C
D-shield, EMC-preferred type
Torsion load/cycles: 5 Mio. at +/- 180°/m
Bending cycles: 5 Mio.

Variant: HELUPOWER® ROBOFLEX® HYBRID PUR UL/CSA (Non-shielded)

Spec Info
HELUDATA® ROBOFLEX®-recycle PUR UL/CSA

HELUDATA® ROBOFLEX®-recycle PUR UL/CSA

PUR robot sensor cable
UL (AWM) 300V
+105°C
Torsion load/cycles: up to 10 Mio. at 360°/m
Bending cycles: up to 10 Mio.

Spec Info
HELUKAT® PROFINET Type R

HELUKAT® PROFINET Type R

Spec Info
PROFIBUS L2 Torsion

PROFIBUS L2 Torsion

Spec Info
MULTIBUS II

MULTIBUS II

Variant: MULTIBUS I

Spec Info

PROFINET Type R Torsion
