Cables, Wires and Accessories for the Oil, Gas and Chemical Industry

Nowadays, more and more research is being conducted into new energy sources that are expected to cover part of the world's energy requirements in a sustainable manner. The oil and gas industry is still the most important branch of industry when it comes to meeting the existing global demand for energy. Because the oil and gas industry is found in the most diverse locations around the world - whether in the deep sea or on land, in the stormy North Sea, at high temperatures in Saudi Arabia or low temperatures in Russia - the cables and pipelines used have to withstand different external conditions.

With HELUKABEL you have the right partner at your side for your projects in the oil and gas industry. HELUKABEL has the right products and solutions for offshore projects on drilling platforms, ships or production platforms, as well as for onshore projects in refineries and petrochemical plants.

In order to meet the different conditions and requirements in the various fields of application, we offer cables, wires and cable accessories with various approvals such as Transport Canada Maritime Safety (TC), American Bureau of Shipping (ABS), De Norske Veritas - Germanischer Lloyd (DNV GL) and many more.

We look forward to assisting you in identifying the best products for your specific application and to answering any questions you might have.

Call us at +1 289-444-5040 or send us an email at: sales@helukabel.ca

Electrical System Solutions for the Oil, Gas & Chemical Industry

See where you can find HELUKABEL products for
on- & offshore oil, gas & chemical applications.

Learn More
On- and offshore oil, gas and chemical applications

Featured Cable Products

HELUDATA® PLTC UL13 PVC/PVC OS 300

HELUDATA® PLTC UL13 PVC/PVC OS 300

300V
Instrumentation Cable
Shielded (Overall), EMC-preferred Type
Low Smoke Low Halogen (LSLH)
Class 1 & 2 Div. 2 Ex. Environ. (NEC Art. 501)

Spec Info
HELUDATA® PLTC UL13 PVC/PVC IOS 300

HELUDATA® PLTC UL13 PVC/PVC IOS 300

300V
Instrumentation Cable
Shielded (Individually & Overall), EMC-preferred Type
Low Smoke Low Halogen (LSLH)
Class 1 & 2 Div. 2 Ex. Environ. (NEC Art. 501)

Spec Info
TRAYCONTROL® 300-C TP

TRAYCONTROL® 300-C TP

300V
Twisted Pair
Flexible
Oil-resistant
Shielded, EMC-preferred Type
Exposed Run: PLTC-ER, ITC-ER
NFPA 79
Variant: TRAYCONTROL® 300 TP
(Non-shielded)

Spec Info
HELUTHERM® PLTC UL 13 ANSI MC 96.1 PVC PVC

HELUTHERM® PLTC UL 13 ANSI MC 96.1 PVC PVC

300V
Thermocouple Cables
Type K/KX, J/JX, T/TX, E/EX

Spec Info
MULTIFLEX 512®-C-PUR UL/CSA

MULTIFLEX 512®-C-PUR UL/CSA

1000V
Shielded, EMC-preferred type
Continuous-flex

Variant: MULTIFLEX 512®-PUR UL/CSA
(Non-shielded)

Spec Info
TRAYCONTROL® 600-C

TRAYCONTROL® 600-C

600/1000V
Black Jacket
Flexible
Oil-resistant
Shielded, EMC-preferred Type
Exposed Run: TC-ER, PLTC-ER, ITC-ER
NFPA 79

Variant: TRAYCONTROL® 600 (Non-shielded)

Spec Info
TRAYCONTROL® X

TRAYCONTROL® X

600/1000V
XLPE Insulation
Flexible
Oil-resistant
Exposed Run: TC-ER, PLTC-ER, ITC-ER
NFPA 79

Spec Info
HELUPOWER® SOOW

HELUPOWER® SOOW

Service cord
Oil-resistant insulation & jacket
Water resistant
600 V
90°C

Spec Info
HELUPOWER® SJOOW

HELUPOWER® SJOOW

Junior service cord
Oil-resistant insulation & jacket
Water resistant
300 V
90°C

Spec Info
TOPFLEX® 1000 VFD

TOPFLEX® 1000 VFD

600/1000V
XLPE Insulation
Shielded, EMC-preferred Type
Flexible Motor Power Supply w/ 3 Symmetrical Grounds
Oil-resistant
NFPA 79

Spec Info
HELUTHERM® 145 UL/CSA

HELUTHERM® 145 UL/CSA

600V
XLPO Insulation
High-temp Resistant

Spec Info
HELUTHERM® SINGLE CORE UL STYLE 3512

HELUTHERM® SINGLE CORE UL STYLE 3512

Silicone Single Conductor
Finely Stranded, Tinned Copper
Temperature-resistant

Spec Info
HELUPOWER® 1000 HY-CARBO SWA

HELUPOWER® 1000 HY-CARBO SWA

600/1000V
Hydrocarbon-resistant
Oil-resistant
Low Smoke Low Halogen (LSLH)
Steel Wire Armored

Spec Info
Explosion-proof Glands

Explosion-proof Glands

Plastic and brass glands that are suitable for use in explosive environments.

Product Info
Intrinsically Safe Cables & Glands

Intrinsically Safe Cables & Glands

Cables and glands for the safe transfer of power and data signals to a hazardous area where the energy levels well below the output required to initiate an explosion.

Product Info

Additional Oil & Gas Cable Products

HELUPOWER® 1000 HY-CARBO

  • 600/1000V, Hydrocarbon-resistant, acc. to IEC 60502

HELUPOWER® 1000 HY-CARBO SWA EMC

  • 600/1000V, Hydrocarbon-resistant, Shielded, Steel Wire Armored, acc. to IEC 60502

HELUPOWER® 1000 HY-CARBO SWA FIRE RES

  • 600/1000V, Hydrocarbon-resistant, Fire-resistant, Steel Wire Armored, acc. to IEC 60502

HELUPOWER® 1000 HY-CARBO LEAD GSTA

  • 600/1000V, Hydrocarbon-resistant, Lead Jacketed, Double Steel Taped Armored, acc. to IEC 60502

HELUDATA® 20276 PE/PVC-TP 30 GRAY

  • High Density PE Conductors, Individually Foiled Pairs, PVC Outer Jacket, 30 V, 60°C

HELUDATA® 2464 PVC/PVC-TP 300 BLACK

  • High-temperature PVC Conductors, Individually Shielded Pairs, PVC Outer Jacket, 300 V, 80°C

HELUDATA® 2919 PE/PVC-TP 30 GRAY

  • Foamed PE Multi-pairs, Overall Shield, PVC Outer Jacket, 30 V, 80°C

HELUDATA® 2919 PE/PVC-TP-C 30 GRAY

  • PE Multi-pairs, Foiled & Braided, PVC Outer Jacket, 30 V, 80°C

HELUDATA® 2092 PE/PVC-TP 300 GRAY

  • PE Conductor Insulation, Individually Shielded Pairs, PVC Outer Jacket, 300 V, 60°C

HELUDATA® 2095 PE/PVC 300 GRAY

  • PE Insulation, Overall Shield, PVC Outer Jacket, 300 V, 80°C

HELUDATA® 2095 PVC/PVC-TP 300 GRAY

  • PVC Insulation, Individually Shielded Pairs, PVC Outer Jacket, 300 V, 80°C, with ripcord

HELUDATA® PLTC UL13 PVC PVC OSA 300

  • PVC/OS/PVC/SWA/PVC, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUDATA® PLTC UL13 PVC PVC IOSA 300

  • PVC/IS/OS/PVC/SWA/PVC, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUDATA® PLTC UL13 XLPE LS0H OS 300

  • XLPE/OS/LS0H, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUDATA® PLTC UL13 XLPE LS0H IOS 300

  • XLPE/IS/OS/LS0H, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUDATA® PLTC UL13 XLPE LS0H OSA 300

  • XLPE/OS/LS0H/SWA/LS0H, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUDATA® PLTC UL13 XLPE LS0H IOSA 300

  • XLPE/IS/OS/LS0H/SWA/LS0H, UL Std. 13 (PLTC), Hazardous Locations Class I & II Div. 2

HELUTHERM® PLTC UL 13 ANSI MC 96.1 XLPE LS0H

  • Halogen-free, UL Std. 13 (PLTC), K/KX, J/JX, T/TX, E/EX

PROFIBUS PA

FOUNDATION™ Fieldbus

Single Pair Ethernet (SPE)

Steel Drag Chains

Designed with the highest mechanical strength and temperature resistance for harsh environments.

Find Out More
Steel Drag Chains
Custom Cable Manufacturing

Custom Cable Manufacturing

When you can't find what you are looking for from our vast product portfolio, let us help you design and build a tailored cable solution unique to your oil, gas or chemical industry application.

Find Out More

References

from the Oil, Gas & Chemical Industry

to the references
drilling rig in arctic area

Downloads
